Auto Trol, Model #: 091-36
auto trol
Blue Bullet 75 Amp Relay Contact Rating
Blue Bullet Senses A.C. Power Line
Blue Bullet Interrupts Power Line When Frequency is Low
Blue Bullet High Interrupt Capacity
Blue Bullet Easy Installation
Blue Bullet 3 Year Warranty
The Auto-Trol low frequency cutout relay is intended to protect A.C. loads by disconnecting them from the power source when the frequency of that power source drops below 60 Hz. This prevents excessive current draw and motor burnout.
Installation is simple, requiring only a connection to the vehicle's 12 volt system and the wiring of the Auto-Trol relay in series with the load.
gray border
gray border
gray border
gray border
  • Auto Trol
    Specifications
  • Instruction
    Manual
  • Related
    Products
Input: 12 Vdc
Sense: 6 to 240 Vac
Relay Closes: 58 + / - 2 Hz.
Relay Opens: 55 + / - 2 Hz.
Relay Contacts: 75 Amps Resistive, 60 Amps Inductive
Weight: 1 lb
Warranty: 3 Years





Auto Trol, 091-36.pdf (41 Kb)
